Case Feet Kit 2
Universal case feet with tilt legs for all types of plastic and metal enclosures with max. 4 mm wall thickness.
Tilt legs:
F Max. 200 N (TÜV SÜD tested: ASTM D642-00 - compression test)
Topple load 3.69 kg (TÜV SÜD tested: DEF STAN 00-35 Part 4 Issue 3 - topple test)
Call us for a free sample.
With tilt legs.
SupplyFoot moulding (x4), tilt leg (x2), TPE non-slip insert (x4), self-tapping screw (x4).
3D/2D download
Generate Your PDF Datasheet for A9257207
Please select the product details you would like to include in the PDF.
Add to my basket
- Technical Data
-
3D-Models & Drawings / Info
- Purchasing Data
Material
Colour
Off-white RAL 9002
Standards
REACH compliant
RoHS compliant
RoHS compliant
Length
34 mm
Width
17 mm
Height
16 mm
Catalogue Pages
- Enclosure feet catalogue (English) 2,446 KB
- Tilt feet load tests report (TÜV SÜD) 809 KB
- Gehäusefüsse Katalog (Deutsch) 2,397 KB
- Catálogo Pies De Caja (Español) 2,589 KB
- Pieds De Boitier Catalogue (Français) 2,343 KB
3D Models
- A9257207.x_t 211 KB
- A9257207.stp 247 KB
- A9257207.sat 238 KB
Weight/1 part
0.03 kg
Customs tariff number
(METCASE product)
(METCASE product)
39269097
Country of manufacture
UK
